SKF NSK NTN Koyo Timken THK Deep Groove Ball Bearing Taper Roller Bearing

SKF NSK NTN Koyo Timken THK Deep Groove Ball Bearing Taper Roller Bearing

INQUIRY

Product Details

Product Tags

Deep groove ball bearing vibration value clearance national standards
Bearing Designation	Size(mm)	Vibration value standard decibels (Db)					Clearance standard (um) without load
Bearing Designation	d×D×W	Z	Z1	Z2	Z3	Z4	C1	C2	C3	C4	C5
6000	10 × 26 × 8	43	42	38	33		0-7	2-13	8-23	14-29	20-37
6001	12 × 28 × 8	44	43	39	34		0-9	3-18	11-25	18-33	25-45
6002	15 × 32 × 9	45	44	40	35		0-9	3-18	11-25	18-33	25-45
6003	17 × 35 × 10	46	44	40	35		0-9	3-18	11-25	18-33	25-45
6004	20 × 42 × 12	47	45	41	36		0-10	5-20	13-28	20-36	28-48
6005	25 × 47 × 12	48	46	42	38		1-11	5-20	13-28	23-41	30-53
6006	30 × 55 × 13	49	47	43	39		1-11	5-20	13-28	23-41	30-53
6007	35 × 52 × 17	51	49	45	41		1-11	6-23	15-33	28-46	40-64
6008	40 × 68 × 15	53	51	45	42		1-11	6-23	15-33	28-46	40-64
6009	45 × 75 × 16	55	53	48	45		1-11	6-23	18-36	30-51	45-73
6010	50 × 80 × 16	57	54	50	47		1-15	8-28	23-43	38-61	55-90
6011	55 × 90 × 18	59	56	52	49		1-15	8-28	23-43	38-61	55-90
6012	60 × 95 × 18	61	58	54	51		1-15	8-28	23-43	38-61	55-90
6013	65 × 100 × 18	49	48	46			1-15	8-28	23-43	38-61	55-90
6014	70 × 110 × 20	50	49	47			1-15	10-30	25-51	46-71	Oct-65
6015	75 × 115 × 20	51	50	48			1-15	10-30	25-51	46-71	Oct-65
6200	10 × 30 × 9	44	42	39	35	30	0-9	3-18	11-25	18-33	25-45
6201	12 × 32 × 10	45	43	39	35	30	0-9	3-18	11-25	18-33	25-45
6202	15 × 35 × 11	46	44	41	36	31	0-9	3-18	11-25	18-33	25-45
6203	17 × 40 × 12	47	45	41	36	31	0-9	3-18	11-25	18-33	25-45
6204	20 × 47 × 14	48	46	42	38	33	0-10	5-20	13-28	20-36	28-48
6205	25 × 52 × 15	49	47	43	40	36	0-11	5-20	13-28	23-41	30-53
6206	30 × 62 × 16	50	48	44	41	37	0-11	5-20	13-28	23-41	30-53
6207	35 × 72 × 17	52	50	46	43	39	0-11	6-23	15-33	28-46	40-64
6208	40 × 80 × 18	54	52	47	44	40	1-11	6-23	15-33	28-46	40-64
6209	45 × 85 × 19	56	54	49	46	43	1-11	6-23	18-36	30-51	45-73
6210	50 × 90 × 20	58	55	51	48	45	1-11	6-23	18-36	30-51	45-73
6211	55 × 100 × 21	60	57	53	50	47	1-15	8-28	23-43	38-61	55-90
6212	60 × 110 × 22	62	59	54	52	48	1-15	8-28	23-43	38-61	55-90
6213	65 × 120 × 23	50	49	47	42		1-15	8-28	23-43	38-61	55-90
6214	70 × 125 × 24	51	50	48	43		1-15	10-30	25-51	46-71	Oct-62
6215	75 × 130 × 25	52	51	49	44		1-15	10-30	25-51	46-71	Oct-62
6300	10 × 35 × 11	46	44	40	37	32	0-9	3-18	11-25	18-33	25-45
6301	12 × 37 × 12	47	45	40	37	32	0-9	3-18	11-25	18-33	25-45
6302	15 × 42 × 13	48	46	42	38	33	0-9	3-18	11-25	18-33	25-45
6303	17 × 47 × 14	49	47	42	38	33	0-9	3-18	11-25	18-33	25-45
6304	20 × 52 × 15	50	48	43	39	34	0-11	5-20	13-28	20-36	28-48
6305	25 × 62 × 17	51	49	44	41	37	1-11	5-20	13-28	23-41	30-53
6306	30 × 72 × 19	52	50	45	42	38	1-11	5-20	13-28	23-41	30-53
6307	35 × 80 × 21	54	52	47	44	40	1-11	6-23	15-33	28-46	40-64
6308	40 × 90 × 23	56	54	49	45	41	1-11	6-23	15-33	28-46	40-64
6309	45 × 100 × 25	58	56	51	47	44	1-11	6-23	18-36	30-51	45-73
6310	50 × 110 × 27	60	57	53	49	46	1-11	6-23	18-36	30-51	45-73
6311	55 × 120 × 29	62	59	54	51	48	1-15	8-28	23-43	38-61	55-90
6312	60 × 30 × 31	64	61	56	53	50	1-15	8-28	23-43	38-61	55-90
6313	65 × 140 × 33	51	50	48	43		1-15	8-28	23-43	38-61	55-90
6314	70 × 150 × 35	52	51	49	44		1-15	10-30	25-51	46-71	Oct-65
6315	75 × 160 × 37	53	52	50	45		1-15	10-30	25-51	46-71	Oct-65
