3500/65-01-00 Bently Nevada Vibration Monitoring System 16 Channel Temperature Monitor
| Manufacturer: | Bently Nevada | Model Number: | 3500/65-01-00 |
|---|---|---|---|
| Product Type: | 16-Channel Temperature Monitor | Agency Approval Option: | None |
| I/O Module Type: | RTD/Isolated Tip TC With Internal Terminations | Country Of OriginF: | USA |
| Factory Warranty: | 12 Months | Weight: | 2 Kg |
| Highlight: | 3500/65-01-00 Bently Nevada Vibration Monitoring System,16 Channel Bently Nevada Vibration Monitoring System,3500 vibration monitoring system | ||
Bently Nevada 3500/65-01-00 16-Channel Temperature Monitor
Description
The 3500/65 monitor provides 16 channels of temperature monitoring and accepts both resistance temperature detector (RTD) and isolated tip thermocouple (TC) temperature inputs. The monitor conditions these inputs and compares them against user-programmable alarm setpoints.
The monitor is programmed using the 3500 Rack Configuration Software. You can configure the 16-Channel Temperature Monitor to accept isolated tip thermocouples, 3-wire RTD, 4-wire RTD, or a combination of TC and RTD inputs.
In Triple Modular Redundant (TMR) configurations, you must install temperature monitors in groups of 3 adjacent monitors. In this configuration the monitor uses 2 types of voting to ensure accurate operation and to avoid singlepoint failures.
Information
3500/65-AA-BB
• A: I/O Module Type
01 RTD/Isolated Tip TC with Internal Terminations
02 RTD/Isolated Tip TC with External Terminations
• B: Agency Approval Option
00 None
01 CSA/NRTL/C
02 CSA/ATEX
Cables
3500/65 Transducer (XDCR) Signal to External Termination (ET) Block Cable
134544-AAAA-BB
• A: Cable Length
0005 5 feet (1.5 metres)
0007 7 feet (2.1 metres)
0010 10 feet (3 metres)
0025 25 feet (7.5 metres)
0050 50 feet (15 metres)
0100 100 feet (30.5 metres)
• B: Assembly Instructions
01 Not Assembled
02 Assembled
Spares
• 172931 3500/65 User Guide
• 145988-02 3500/65 Monitor
• 172103-01 3500/65 RTD/Isolated Tip TC I/O Module, Internal Terminations
• 173005 Connector Header, Internal Termination, 20-position, Black
• 172109-01 3500/65 RTD/ Isolated Tip TC I/O Module, External Terminations
• 172115-01 RTD/Isolated Tip TC External Termination Block (Euro Style Connectors) Specifications
