3500/60-01-CN Bently Nevada Vibration Monitoring System 3500/60 No Recorder Outputs
| Manufacturer: | Bently Nevada | Model Number: | 3500/60-01-CN |
|---|---|---|---|
| Product Type: | 3500/60 No Recorder Outputs | I/O Module Type: | RTD/TC Non-isolated I/O Module Internal Terminations |
| Agency Approval: | Approvals Country Specific | Power Consumption: | Nominal Consumption Of 7 Watts |
| Country Of Origin: | USA | Shipping Weight: | 2 Kg |
| Highlight: | 3500/60-01-CN bently nevada vibration monitoring system 3500,bently nevada vibration monitoring system 3500,bently nevada 3500 | ||
Bently Nevada 3500/60-01-CN Recorder Outputs
Description
The 3500/60 modules provide six channels of temperature monitoring and accept both Resistance Temperature Detector (RTD) and Thermocouple (TC) temperature inputs. The modules condition these inputs and compare them against user-programmable alarm setpoints. The 3500/60 and 3500/61 provide identical functionality except that the 3500/61 provides recorder outputs for each of its six channels while the 3500/60 does not.
The user programs the modules to perform either RTD or TC temperature measurements using the 3500 Rack Configuration Software. Different I/O modules are available in RTD/TC non-isolated or TC isolated versions. The user can configure the RTD/TC non-isolated version to accept either TC or RTD, or a mixture of TC and RTD inputs. The TC isolated version provides 250 Vdc of channel-to-channel isolation to protect against external interference.
When used in a Triple Modular Redundant (TMR) configuration, temperature monitors must be installed adjacent to each other in groups of three. When used in this configuration, the system employs two types of voting to ensure accurate operation and to avoid single-point failures.
Information
Without Recorder Outputs
3500/60-AA-BB
• A:I/O Module Type
01 RTD/TC Non-isolated I/O Module Internal Terminations
02 RTD/TC Non-isolated I/O Module External Terminations
03 TC Isolated I/O Module Internal Terminations
04 TC Isolated I/O Module External Terminations
05 RTD/TC Non-isolated I/O Module with Internal Barriers
• B:Agency Approval Option
00 None
01 CSA/NRTL/C (Class 1, Div 2)
02 ATEX/ IECEx/ CSA (Class 1, Zone 2)
Cables
3500/60 and 3500/61 Transducer (XDCR) Signal to External Termination (ET) Block Cable
134544-AAAA-BB
• A:Cable Length
0005 5 feet (1.5 metres)
0007 7 feet (2.1 metres)
0010 10 feet (3.0 metres)
0025 25 feet (7.5 metres)
0050 50 feet (15 metres)
0100 100 feet (30.5 metres)
• B:Assembly Instructions
01 Not assembled
02 Assembled
3500/60 -Specific
• 163179-01 3500/60 Temperature Monitor (without recorders)
• 133827-01 3500/60 RTD/TC Non-Isolated I/O Module, External Terminations.
• 133819-01 3500/60 RTD/TC non-Isolated I/O Module, Internal Terminations
• 133835-01 3500/60 TC Isolated I/O Module, Internal Terminations.
• 133843-01 3500/60 TC Isolated I/O Module, External Terminations.
• 136711-01 3500/60 RTD/TC I/O Module with Internal Barriers and Internal Terminations. (Not-Isolated)
